AB15810C - Desiccant Breather - 4.8 fl.oz retention - 75 gpm airflow - with inflow & outflow check valves
Specs:
Standard Life Desiccant Breather with Inflow & Outflow Check Valves. Click Here for No Check-Valve version.
Recommended for 43-240 gallons storage tanks, drums, totes, transformers and hydraulic applications in low moisture environments.
1″ Sure-Fit (NPT, BSPP, NPSM) connection.
Max Moisture Retention = 142 ml (4.8 fl oz), Max Airflow at 1psid = 10 cfm (283 lpm or 75 gpm).
Largest OD = 10.41 cm (4.1 in).
Length / Overall Height = 15.52 cm (6.11 in).
Dual Phase Micro-glass media with 2-stage filtration.
Filter Efficiency = 99.9% @ 1 micron.
Operating Temperature Range = (-20°F to 200°F) or (-29°C to 93°C).
Moisture-Absorbing Desiccant: Silica Gel.
Body Material: ABS, Nylon, Polypropylene, Buna-N.
Compatible with a wide range of mineral oils, synthetic oils and diesel fuels.
Replace when color change from Orange to Green.
Specs:
Standard Life Desiccant Breather with Inflow & Outflow Check Valves. Click Here for No Check-Valve version.
Recommended for 43-240 gallons storage tanks, drums, totes, transformers and hydraulic applications in low moisture environments.
1″ Sure-Fit (NPT, BSPP, NPSM) connection.
Max Moisture Retention = 142 ml (4.8 fl oz), Max Airflow at 1psid = 10 cfm (283 lpm or 75 gpm).
Largest OD = 10.41 cm (4.1 in).
Length / Overall Height = 15.52 cm (6.11 in).
Dual Phase Micro-glass media with 2-stage filtration.
Filter Efficiency = 99.9% @ 1 micron.
Operating Temperature Range = (-20°F to 200°F) or (-29°C to 93°C).
Moisture-Absorbing Desiccant: Silica Gel.
Body Material: ABS, Nylon, Polypropylene, Buna-N.
Compatible with a wide range of mineral oils, synthetic oils and diesel fuels.
Replace when color change from Orange to Green.
Specs:
Standard Life Desiccant Breather with Inflow & Outflow Check Valves. Click Here for No Check-Valve version.
Recommended for 43-240 gallons storage tanks, drums, totes, transformers and hydraulic applications in low moisture environments.
1″ Sure-Fit (NPT, BSPP, NPSM) connection.
Max Moisture Retention = 142 ml (4.8 fl oz), Max Airflow at 1psid = 10 cfm (283 lpm or 75 gpm).
Largest OD = 10.41 cm (4.1 in).
Length / Overall Height = 15.52 cm (6.11 in).
Dual Phase Micro-glass media with 2-stage filtration.
Filter Efficiency = 99.9% @ 1 micron.
Operating Temperature Range = (-20°F to 200°F) or (-29°C to 93°C).
Moisture-Absorbing Desiccant: Silica Gel.
Body Material: ABS, Nylon, Polypropylene, Buna-N.
Compatible with a wide range of mineral oils, synthetic oils and diesel fuels.
Replace when color change from Orange to Green.
